Vention 1 In 2 Out VGA Splitter Black Aluminium Alloy Type
Share
-8%New

Vention 1 In 2 Out VGA Splitter Black Aluminium Alloy Type

in VGA Cables/ Adapters

KSh2,300 Save:KSh200(8%) Ex VAT

Available in stock

Key Features & Benefits

  • 1-In-2-Out Signal Splitting: Takes one VGA input and distributes it identically to two VGA outputs simultaneously. Both displays show the same image in real time — this is a mirror/clone output, not an extended desktop. It is the correct tool when identical content is needed on two screens at once.
  • Aluminium Alloy Construction: The metal housing dissipates heat more effectively than plastic and resists the physical wear of regular handling and installation. It feels substantially more robust than budget plastic splitters and is better suited to semi-permanent or permanent AV installations.
  • Full HD Resolution Support: Supports resolutions up to 1920×1080 at 60Hz, ensuring sharp, stable output on both connected displays simultaneously, provided the source device and both monitors support that resolution.
  • Plug-and-Play Operation: No drivers, software, or configuration needed. Connect the source device and both displays, and the splitter distributes the signal immediately across both outputs without any setup steps.
  • Bus-Powered — No External Power Required: The splitter draws its operating power directly from the VGA port on the source device, eliminating the need for a separate power adapter or USB power cable in standard configurations.
Category:
Description

Vention 1 In 2 Out VGA Splitter – Black Aluminium Alloy

The Vention 1 In 2 Out VGA Splitter is a compact signal splitter that takes a single VGA output from a computer and mirrors it simultaneously across two VGA displays. Built from aluminium alloy, it’s more durable than the plastic-bodied splitters common in this category. It suits IT administrators, educators, trainers, and AV installers who need to show the same content on two screens at once — a presenter’s laptop mirrored to both a confidence monitor and a front-of-room display, for instance, or a single workstation output shown on two monitors in a reception or retail environment. No software, drivers, or external power supply are required.

Technical Specifications

Signal Routing

  • Input Ports: 1× VGA (Female)
  • Output Ports: 2× VGA (Female)
  • Function: Mirror / clone (identical signal to both outputs simultaneously)
  • Extended Desktop: Not supported — both outputs display the same image

Video Performance

  • Maximum Resolution: 1920×1080 (Full HD) at 60Hz
  • Signal Type: Analog (VGA)
  • Bandwidth: Supports standard VGA signal frequencies
  • HDR: Not supported — VGA is an analog standard

Audio

  • Audio Transmission: Not supported — VGA carries no audio signal

Build & Physical

  • Housing Material: Aluminium alloy
  • Color: Black
  • Connector Finish: Gold-plated VGA pins
  • Form Factor: Compact desktop unit

Power

  • Power Source: Bus-powered via VGA port (no external adapter required)
  • External Power: Not required in standard use; some setups with long cable runs or lower-output VGA ports may benefit from an optional USB power input if available

Compatibility

  • Source Devices: Any desktop, laptop, or device with a VGA output
  • Display Devices: Any two monitors, projectors, or screens with VGA inputs
  • OS Support: Windows, macOS, Linux — no drivers required
  • Cable Requirements: VGA cables not included; standard male-to-female VGA cables required to connect source and displays
